Icom CI-V Explorer

Paste this into your agent's skill configuration to give it CI-V reference capabilities without OpenAPI tool generation:

---
name: civ-reference
description: >
  Expert guidance for ICOM CI-V command reference. Queries the CI-V REST API
  (https://icom-civ.stevendodd.net) for authoritative command data. Advises on command
  construction, data encoding, sub-commands, and protocol details. Supports IC-705,
  IC-7100, IC-7300, IC-7300 MK2, IC-7610, IC-7760, and IC-9700. Load this skill for
  any question about CI-V commands, hex codes, data formats, or encoding for any
  supported Icom radio.
---

# CI-V Reference Skill

## Data Sources

### 1. Primary — CI-V REST API (authoritative, always up-to-date)

**Base URL:** `https://icom-civ.stevendodd.net`

A read-only HTTPS REST API serving the parsed CI-V command tables and capability
data for all supported radios. The API is the single source of truth — it is
maintained alongside the CSVs and reflects the latest corrections. Always query
the API first when network access is available.

Use `curl` (or `webfetch`) against these endpoints:

| Endpoint | Purpose |
|----------|---------|
| `GET /radios` | List all radios with default CI-V addresses and command counts |
| `GET /radios/{radio_id}` | Single radio summary (id, name, address, command_count) |
| `GET /radios/{radio_id}/capabilities` | Per-radio capability flags (satellite_mode, dv_mode, attenuator, …) |
| `GET /radios/{radio_id}/commands?q=<query>&limit=<n>&offset=<n>` | List/search commands for one radio |
| `GET /commands?radio_id=<id>&q=<query>&limit=<n>&offset=<n>` | Cross-radio command search |
| `POST /feedback` | Submit a correction for human review (see below) |
| `GET /health` | Service health check |

`radio_id` values: `705`, `7100`, `7300`, `7300mk2`, `7610`, `7760`, `9700`.

**Command object schema** (from `/commands` and `/radios/{id}/commands`):
```json
{
  "radio_id": "9700",
  "cmd": "16",
  "sub_cmd": "02",
  "data": "00 to 03",
  "description": "Send/read the Preamp/External Preamp ..."
}
```
- `cmd` — primary command hex (no `0x` prefix), e.g. `"16"`, `"1A"`
- `sub_cmd` — sub-command hex; may be empty `""` or a comma-separated multi-byte
  string like `"05,02"` (meaning sub-cmd bytes `05` then `02`). Empty string = no sub-command
- `data` — data payload description from the manual (free text, e.g. `"00 to 03"`)
- `description` — human-readable description of the command

**Capability object schema** (from `/radios/{id}/capabilities`):
```json
{
  "name": "satellite_mode",
  "label": "Satellite Mode",
  "description": "Satellite mode (split TX/RX bands with independent VFOs)",
  "command_evidence": "0x16 0x5A",
  "radios": {"705": false, "7100": false, ..., "9700": true}
}
```
- `name` — machine-readable capability name (snake_case, e.g. `"satellite_mode"`)
- `label` — human-friendly display label (Title Case, e.g. `"Satellite Mode"`)
The `radios` map values are booleans or descriptive strings (e.g. `"external (AH-705)`,
`"20 dB"`). When filtering for one radio, read the matching key.

**Pagination:** `limit` (1–500, default 100) and `offset` (default 0). The response
includes `total`, so iterate with offset if `total > limit`. Always check `total`
and page through for complete results.

**Search (`q`):** matches across `cmd`, `sub_cmd`, `data`, and `description`. It is a
substring/keyword search, not a structured lookup. For an exact command-byte
lookup, filter client-side on `cmd` + `sub_cmd` from a `q` query, or fetch the
radio's full command list (page through if needed) and match.

**Feedback / corrections:** the API is read-only; `POST /feedback` is the one write
path. Submissions are appended to a JSONL log for human review and never mutate the
reference data. Do not POST feedback autonomously — surface the discrepancy to the
user and let them decide (see "Handling Discrepancies" below).

### Supported Radios

| Radio | ID | CI-V Address | API radio_id | Notes |
|-------|-----|-------------|--------------|-------|
| IC-9700 | 9700 | 0xA2 | `9700` | VHF/UHF, satellite mode, DV/DD |
| IC-7610 | 7610 | 0x98 | `7610` | HF/50MHz, dual watch, band selector |
| IC-7300 | 7300 | 0x94 | `7300` | HF/50MHz, built-in tuner, APF |
| IC-7300 MK2 | 7300mk2 | 0xB6 | `7300mk2` | HF/50MHz, newer revision of 7300 |
| IC-705 | 705 | 0xA4 | `705` | HF/VHF/UHF portable, DV, WFM, GPS |
| IC-7100 | 7100 | 0x88 | `7100` | HF/VHF/UHF, DV/DD, WFM, GPS |
| IC-7760 | 7760 | 0xB2 | `7760` | HF/50MHz, similar to 7610 |

## CI-V Frame Structure

All CI-V frames follow this structure:

```
FE FE [from_addr] [to_addr] [cmd] [sub_cmd...] [data...] FD
```

- Preamble: `FE FE` (2 bytes)
- From address: Controller address (typically `E0` for serial, `E1` for UDP)
- To address: Radio address (`A2` for IC-9700, `98` for IC-7610, …)
- Command byte: From the API `cmd` field
- Sub-command bytes: From the API `sub_cmd` field (comma-separated → individual bytes; empty → none)
- Data bytes: From the API `data` field description (0 or more bytes)
- Postamble: `FD` (1 byte)

## Data Encoding Rules

### Frequencies
- Frequencies use **BCD encoding, little-endian** (2 digits per byte, LSB first).
- Example: 144.000000 MHz → `00 00 00 44 01` (5 bytes for IC-9700)

### Percentage Values (Power, SQL, Meter levels)
- Use **decimal-nibble encoding**: each nibble holds one decimal digit (0-9).
- 2-byte format: `0x0255` = 100%, `0x0128` = 50%, `0x0000` = 0%.
- Extract with `int(b.hex())`. **NOT** `int.from_bytes()` — that would interpret as binary.

### ON/OFF Values
- `00` = OFF, `01` = ON (single byte)

### Mode Encoding
- Command `0x06` (Set mode) uses specific byte values per mode
- See the IC-9700 manual for the complete mode table

## Handling Discrepancies

The API is the authoritative source, but it is not assumed to be 100% correct.
CI-V reference data is hand-transcribed from Icom manuals and may contain errors.
When this skill detects a discrepancy **do not silently assume the API is right.**

Instead:

1. **Surface the discrepancy explicitly** to the user. State what each source says:
   the API value, the conflicting source value (codebase/CSV/manual), and where each
   came from. Lead with the assumption that the API is the likely error.
2. **Do not auto-correct** implementation code or pick a "winner" on the skill's own
   judgement. CI-V byte errors cause silent data corruption or radio malfunction so a human must decide.
3. **Offer options** to the user, for example:
   - Treat the API as wrong (default when it conflicts with the codebase) and submit
     feedback to correct the API
   - Investigate further (consult the manual text in `icom manuals/`)
   - Trust the API value anyway and change the codebase (requires explicit approval)
4. **Use the `question` tool** when the choice materially affects the answer or any
   code change. Present the conflicting values as the options, with the
   "API is wrong / trust the codebase" option first and marked as recommended.
5. **Feedback submissions are user-driven only.** Never POST to `/feedback`
   autonomously. If the user wants to report an API error (the usual case for a
   codebase conflict), build the feedback payload and show it to them for
   confirmation before sending, or let them submit it themselves. The feedback
   schema is:
   ```json
   {
     "radio_id": "9700",
     "cmd": "1A",
     "sub_cmd": "05",
     "field": "data",
     "capability_name": "",
     "suggested_value": "00 to 03",
     "notes": "Manual says ...",
     "submitter": ""
   }
   ```
   Required: `radio_id`, `field`, `suggested_value`.

Treat API and CSV command-count mismatches, differing `sub_cmd` byte sequences,
differing `data` ranges, and missing/extra commands as discrepancies to confirm —
not as bugs to fix unilaterally.

## Expert Guidance Workflow

When using this skill to answer CI-V questions:

1. **Query the API first.** Use `curl` against the relevant endpoint:
   ```bash
   curl -s "https://icom-civ.stevendodd.net/radios/9700/commands?q=1A%2005&limit=50" | python3 -m json.tool
   curl -s "https://icom-civ.stevendodd.net/commands?q=satellite&limit=100" | python3 -m json.tool
   curl -s "https://icom-civ.stevendodd.net/radios/7610/capabilities" | python3 -m json.tool
   ```
   Note: `q` is a substring search. For an exact command-byte lookup, fetch the
   radio's commands with a broad `q` (or no `q`, paging through `limit`/`offset`)
   and filter client-side on `cmd`+`sub_cmd`.

2. **Always specify the radio.** The SET menu sub-commands (`0x1A 0x05`) are
   completely different between radios. Always pass the `radio_id` / `--radio`.

3. **Check capabilities.** Query `/radios/{id}/capabilities` to confirm a radio supports a feature before
   advising on its command bytes.

4. **Encoding matters.** Remind about decimal-nibble encoding for percentages, BCD
   for frequencies, and `byteorder="big"` for `int.from_bytes()` calls. These are
   the highest-risk areas. The API `data` field is a description (e.g. `"00 to 03"`),
   not the encoded bytes — apply the encoding rules to convert.

5. **Send vs Read.** The API does not currently tag direction. Distinguish
   manually: Read commands omit data bytes; the radio replies with the current
   value. Send (write) commands include the data bytes. The `data` field's phrasing
   often hints at this (`"Send/read the …"` = both; a bare range like `"00 to 03"`
   is the data payload for Send, and the value returned for Read).

6. **Discrepancies are findings, not fixes.** If API, CSV, implementation, or manual
   disagree on a command byte, sub-command, or data encoding, surface it to the user
   per "Handling Discrepancies" above. Do not auto-correct.
